StarTech.com 7-Port USB 2.0 Hub - Metal Industrial USB-A Hub with ESD Protection & 350W Surge Protection - Din Rail, Wall or Desk Mountable - TAA Compliant USB Expander Hub

SKU
ST7200USBM
kr 1 190,78 eks. mva.
12 På lager
StarTech.com 7-Port USB 2.0 Hub - Metal Industrial USB-A Hub with ESD Protection & 350W Surge Protection - Din Rail, Wall or Desk Mountable - TAA Compliant USB Expander Hub (ST7200USBM)
Industrial Grade | 15kV Air | 8kV Contact | Metal | Mountable | DIN Rail | 480 Mbps

This TAA compliant 7-port industrial USB 2.0 hub gives you the scalability you need in harsh industrial environments, product and repair labs, conference rooms or office workstations. With its rugged industrial grade metal housing, it is designed to meet the advanced requirements of connecting a high number of devices in factories and office environments.

Perfect for Harsh Environments

This industrial USB hub delivers reliable performance with a metal, heavy-duty housing. It supports wide-range 7-24V DC terminal block input, giving you the flexibility to power the hub as required, based on your own power input capabilities.

Perfect for factory environments, the rugged hub also supports a wide operating temperature range (0°C to 55°C) and offers surge and ESD protection to each USB port, which can help prevent damage to your connected devices.

Connect More USB Devices

Designed for a high volume of connections, this robust USB 2.0 hub offers 7 connection ports, for connecting more USB devices and peripherals.

Locate the Hub Where You Need It Most

With versatile installation options, you can install the hub where it’s best suited for your environment. With built-in mounting brackets and included DIN mount rails, you can securely mount the USB 2.0 hub to most surfaces such as a wall, under a desk or rack.

StarTech.com offers an external power adapter, ITB20D3250, sold separately. The universal DC power adapter can be used as an alternative, back up or replacement power supply for StarTech.com’s line of industrial USB hubs.

Works with Older USB Devices

The rugged USB hub supports the full 480 Mbps bandwidth of USB 2.0 and is backward compatible with previous USB devices.

The ST7200USBM is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage
SKU ST7200USBM
EAN 0065030837910
Specification
Ports & interfaces
Host interfaceUSB 2.0 Type-B
Terminal block portYes
Hub interfacesUSB 2.0
USB 2.0 ports quantity7
Ports quantity7
Features
Surge protectionYes
Plug and PlayYes
LED indicatorsYes
Hot-swapYes
Product colourBlack
CertificationCE, FCC, RoHS, REACH, TAA
Data transfer rate480 Mbit/s
Housing materialSteel
Host interfaceUSB 2.0 Type-B
Data transmission
Data transfer rate480 Mbit/s
Power
Input voltage7 - 24 V
Technical details
Plug and PlayYes
Hot-swapYes
Product colourBlack
Performance
CertificationCE, FCC, RoHS, REACH, TAA
Surge protectionYes
Plug and PlayYes
Hot-swapYes
Data transfer rate480 Mbit/s
Mean time between failures (MTBF)170227 h
Harmonized System (HS) code84719000
Weight & dimensions
Weight283 g
Width61.5 mm
Depth133 mm
Height36.3 mm
Package width216 mm
Package depth151 mm
Package height51 mm
Package weight500 g
Packaging data
Package width216 mm
Package depth151 mm
Package height51 mm
Package weight500 g
Packaging content
ManualYes
Cables includedUSB
DIN rail kit includedYes
Design
LED indicatorsYes
Product colourBlack
CertificationCE, FCC, RoHS, REACH, TAA
Operational conditions
Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-20 - 85 °C
Operating relative humidity (H-H)5 - 95%
Certificates
CertificationCE, FCC, RoHS, REACH, TAA
Indication
LED indicatorsYes
Logistics data
Master (outer) case width436 mm
Master (outer) case length514 mm
Master (outer) case height264 mm
Products per master (outer) case25 pc(s)
Harmonized System (HS) code84719000
Other features
ChipsetTerminus - FE2.1
Manufacturer StarTech.com
