Specification |
Ports & interfaces |
---|
Internal | No | USB version | 3.2 Gen 1 (3.1 Gen 1) | USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 | Ethernet LAN (RJ-45) ports | 1 | Interface | Ethernet | Host interface | USB | Connectivity technology | Wired | Bandwidth |
---|
Full duplex | Yes | Maximum data transfer rate | 5000 Mbit/s | Network |
---|
Chipset | Genesys Logic - GL3522, ASIX - AX88179 | Jumbo frames | 4000 | Ethernet LAN | Yes | Cabling technology | 10/100/1000BaseT(X) | Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u | Wake-on-LAN ready | Yes | Auto MDIX IEEE | Yes | Jumbo frames support | Yes | Full duplex | Yes | Ethernet LAN data rates | 10,100,1000 Mbit/s | Maximum data transfer rate | 5000 Mbit/s | Auto-negotiation | Yes | Flow control support | Yes | Technical details |
---|
Product colour | Black | Wake-on-LAN ready | Yes | Auto MDIX IEEE | Yes | Cable length | 0.148 m | Harmonized System (HS) code | 85176990 | Compliance certificates | RoHS | Power |
---|
Power plug type | Type H | Output voltage | 5 V | Output current | 2 A | Input current | 0.3 A | Power consumption (typical) | 10 W | AC input voltage | 100-240 V | Design |
---|
Product colour | Black | Chipset | Genesys Logic - GL3522, ASIX - AX88179 | Certification | CE, FCC | Internal | No | LED indicators | Activity, Link | Housing material | Aluminium | Software |
---|
Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura | Linux operating systems supported | Yes | Other operating systems supported | ChromeOS | Indication |
---|
LED indicators | Activity, Link | System requirements |
---|
Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 | Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura | Linux operating systems supported | Yes | Other operating systems supported | ChromeOS | Operational conditions |
---|
Operating temperature (T-T) | 0 - 50 °C | Storage temperature (T-T) | -10 - 75 °C | Operating relative humidity (H-H) | 0 - 85% | Weight & dimensions |
---|
Width | 43 mm | Depth | 87 mm | Height | 14 mm | Weight | 62 g | Package width | 217 mm | Package depth | 152 mm | Package height | 53 mm | Package weight | 374 g | Packaging data |
---|
Drivers included | Yes | Included power plug types | AU, EU, NA, UK | AC adapter included | Yes | Package width | 217 mm | Package depth | 152 mm | Package height | 53 mm | Package weight | 374 g | Manual | Yes | Packaging content |
---|
Manual | Yes | Drivers included | Yes | Included power plug types | AU, EU, NA, UK | AC adapter included | Yes | Performance |
---|
USB data transfer rates | 12,480,5000 Mbit/s | Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 | Wake-on-LAN ready | Yes | Auto MDIX IEEE | Yes | Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura | Linux operating systems supported | Yes | Other operating systems supported | ChromeOS | Cable length | 0.148 m | Auto-negotiation | Yes | Certificates |
---|
Certification | CE, FCC | Other features |
---|
Chipset | Genesys Logic - GL3522, ASIX - AX88179 | Manual | Yes | USB data transfer rates | 12,480,5000 Mbit/s | Power plug type | Type H | Jumbo frames | 4000 | Housing material | Aluminium | Flow control support | Yes | Cable length | 0.148 m | AC input voltage | 100-240 V | Harmonized System (HS) code | 85176990 | Logistics data |
---|
Master (outer) case width | 323 mm | Master (outer) case length | 452 mm | Master (outer) case height | 580 mm | Products per master (outer) case | 40 pc(s) | Harmonized System (HS) code | 85176990 |
|
